English
5MP PS CMOS Image Sensor
DWDR, Day/Night(ICR), AWB, AGC, BLC, HLC, 2D NR
3.6mm Fixed lens (2.8 mm optional)
IR Range of 20 Mtrs., IP67,12 VDC
Built-in mic
CVI/CVBS/AHD/TVI switchable
- Max 25 fps@5MP (16
- 9 video output)
- Image Sensor
- 5MP PS CMOS Image Sensor
- Minimum Illumination
- 0.05 lux@F1.6 (Color, 30 IRE) 0.005 lux@F1.6 (B/W, 30 IRE) 0 lux (Illuminator on)
- Max. Resolution
- 2880 (H) × 1620 (V)
- Shutter Speed
- PAL: 1/25 s–1/100000 s NTSC: 1/30 s–1/100000 s
- White Balance
- Auto; Area white balance
- Gain Control (AGC)
- Auto/Manual
- Lens
- 3.6mm (2.8mm optional)
- Max. Aperture
- F1.6
- DORI Distance
- 2.8 mm: Detect: 56 Mtr., Observe: 22.4 Mtr., Recognize: 11.2 Mtr., Identify : 5.6 Mtr. 3.6 mm: Detect: 76 Mtr., Observe: 30.4 Mtr., Recognize: 15.2 Mtr., Identify : 7.6 Mtr.
- Lens Type
- Fixed-focal
- Close Focus Distance
- 3.6 mm: 1.3 m (4.27 ft), 2.8 mm: 0.8 m (2.62 ft)
- Lens Mount
- M12
- Back Light Compensation
- BLC / HLC / DWDR
- Angle Adjustment
- Pan: 0°–360°, Tilt: 0°–90°, Rotation: 0°–360°
- Angle of view
- 3.6 mm: H: 92°; V: 48°; D: 109°, 2.8 mm: H: 106°; V: 56°; D: 125°
- S/N Ratio
- >65 dB
- Video Streaming
- CVI: PAL: 5M@25 fps
- 4M@25 fps
- 1080p@25 fps NTSC: 5M@25 fps
- 4M@30 fps
- 1080p@30 fps AHD: PAL: 4M@25 fps
- NTSC: 4M@30 fps TVI: PAL: 4M@25 fps
- NTSC: 4M@30 fps CVBS: PAL: 960H
- NTSC: 960H
- Resolution
- 5M (2880 × 1620); 4M (2560 × 1440); 1080p (1920 × 1080); 960H (960 × 576/960 × 480)
- Video Output
- Video output choices of CVI/TVI/AHD/CVBS by one BNC port
- Noise Reduction
- 2D NR
- Privacy Mask
- Off/On (8 areas, rectangle)
- Audio
- Built-in Mic
- Day/Night
- Auto(ICR)/Color/B/W
- Mirror Function
- Support
- IR Distance
- IR Range of 20 Mtr.
- Warm Light Range
- Warm Light Range of 20 Mtr.
- IR Control
- Auto/Manual
- Dual LED Number
- 2 (Warm light) + 2 (IR light)
- IR Mode
- Smart IR&WL WL Mode; IR Mode
- Iris Control
- Fixed
- Weatherproof Standard
- IP67
- Operating Temperature
- –40 °C to +60 °C (–40 °F to +140 °F)
- Operating Humidity
- <95% (RH), non-condensing
- Storage Temperature
- –40 °C to +60 °C (–40 °F to +140 °F)
- Storage Humidity
- <95% (RH), non-condensing
- Power Source
- 12 VDC ± 30%
- Power Consumption
- Max 4.5 W (12 VDC, WLED on)
- Casing
- Plastic
- Dimension
- 163.4 mm × 69.7 mm × 70 mm (6.43" × 2.74" × 2.76")
- Weight
- 0.19 kg
