1/2.8" 2.4MP CMOS Image Sensor (0.9071 centimeters)
Max 30fps@2.4MP
WDR(120dB), Day/Night(ICR), 3D/2D-DNR, AWB, AGC, BLC, HLC
3.6mm fixed lens (2.8mm Optional)
IR Range of 20 Mtrs., Smart IR, IP67, IK10
IP6K9K, Shock-proof
Audio in interface, Support Built-in Mic
HDCVI output (Aviation connector)
HD, SD and Two Analog format Output
- Image Sensor
- 1/2.8" 2.4MP PS CMOS (0.9071 centimeters)
- Minimum Illumination
- 0.004Lux/F1.6, 30IRE, 0Lux IR on
- S/N Ratio
- More than 65dB
- Shutter Speed
- PAL: 1/4s~1/100000s NTSC: 1/3s~1/100000s
- Gain Control (AGC)
- AGC
- White Balance
- Auto / Manual
- Back Light Compensation
- BLC / HLC / WDR (120dB)
- Lens
- 3.6mm (2.8mm Optional)
- Iris
- Fixed
- Lens Type
- Fixed
- Max Aperture
- F1.6
- Angle of View
- H: 86.9° (110°)
- ICR
- Auto (ICR) / Manual
- DORI Distance
- 2.8mm- 39m (Detect) 15m(Observe) 8m(Recognize) 4m(Identify) 3.6mm- 55m (Detect) 22m(Observe) 11m(Recognize) 6m(Identify)
- Close Focus Distance
- 1200mm (500mm); 47.2'' (19.7'')
- Video Streaming
- 25/30fps@1080P, 25/30/50/60fps@720P
- Audio
- Built-in Mic
- IR
- IR Range of 20 Mtr., Smart IR
- Audio Input
- 1 Ch.
- Weatherproof Standard
- IP67 & IK10
- Casing
- Aluminium
- Operating Temperature
- -40°C ~ +60°C (-40°F ~ +140°F)
- Humidity
- Less than 90% RH
- Power Source
- 12V DC ±30%
- Power Consumption
- Max. 3.6W
- Dimension
- Φ106mm×50.3mm
- Weight
- 0.31kg
