7 inch IPS display, resolution 1024×600 (17.78cm)
Support face unlock, IC card unlock, and password unlock; unlock by period
With face detection box; the largest face among faces that appear at the same time is recognized first; the maximum face size can be configured on the web
2MP wide-angle WDR lens; with auto/manual fill light
With face recognition algorithm, the access controller can recognize more than 360 positions on human face
Face verification accuracy>99.5%; face comparison speed 0.35s per person; low false recognition rate
Support profile recognition; the profile angle is 0°–90°
Holds 50, 000 users, 50, 000 faces, 50, 000 cards, 50, 000 passwords, and 50 administrators
Support liveness detection
Support duress alarm, tamper alarm, intrusion alarm, door contact timeout alarm, illegal card exceeding threshold alarm, and more
Support general users, patrol users, VIP users, guest users, and the disabled users
With 4 unlock status display modes
- Face-camera distance
- 0.3 m–2.0 m; human height: 0.9 m–2.4 m
- Main Processor
- Embedded Processor
- Internet Protocol
- IPv4, RTSP, RTP, TCP, UDP, P2P
- OSDP Protocol
- Yes
- Interoperability
- CGI
- SDK and API
- Support SDK
- Display Size
- 7 inch IPS (17.78cm)
- Screen type
- Capacitive touch screen
- Resolution
- 600(H)×1024(V)
- Camera
- 2 MP CMOS camera
- WDR
- 120dB
- Light Compensation
- Auto white light; Auto IR light
- Status Indicator
- 1 indicator light. Red: Error; Green: Normal; Blue: Working.
- Voice Prompt
- Yes
- Housing Material
- PC+ABS
- Unlock Mode
- Card/remote/password/face unlock and unlock through their combinations
- Card Reading Type
- IC card
- Period List
- 128
- Holiday Period
- 128
- First-Card Unlock
- Yes
- Remote Verification
- Yes
- Peripheral Card Reader
- 1 RS-485, 1 Wiegand
- Multiple Card Authentication
- Yeshttps://www.cpplusworld.com/Admin/EditItem?Id=1648
- Real-Time Surveillance
- Yes
- Web Configuration
- Yes
- Card reading distance
- 1cm–5cm
- Face Recognition Range
- Face-camera distance: 0.3 m–2.0 m; Human height: 0.9 m–2.4 m
- Face Verification Accuracy
- >99.5%
- Face Recognition Time
- 0.35s
- User Capacity
- 50, 000
- Face Image Capacity
- 50, 000
- Card Capacity
- 50, 000
- Password Capacity
- 50, 000
- Record Capacity
- 100, 000 records
- RS-485
- 1
- RS-232
- 1
- Wiegand
- 1 input/output
- USB
- 1 USB2.0 port
- Ethernet
- 1 (input or output)
- Ethernet
- 1 10M/100M Ethernet Port
- Alarm IN
- 2 (Switch quantity)
- Alarm Out
- 2 (Relay)
- Exit Button
- 1
- Door Status Detection
- 1
- Lock Control
- 1
- Anti-Passback
- Yes
- Tamper Alarm
- Yes
- Duress
- Yes
- Door Sensor Timeout
- Yes
- Intrusion
- Yes
- Illegal Card Exceeding Threshold
- Yes
- Power Supply
- Provided
- Power Supply Mode
- DC 12V 2A
- Power Consumption
- 12W
- Production Dimensions
- 283.0mm×130.0mm×36.9mm (11.14
- Working Temperature
- -10°C to +55°C (+14°F to +131°F)
- Working Humidity
- 0%RH–90%RH (non-condensing)
- Working Environment
- Indoor
- Gross weight
- 1.8kg
- Installation Method
- Wall Mounted
