Supports HDCVI, AHD, TVI, CVBS and IP video input
Supports up to 5 Channels IP camera input and each channel can be up to 2MP
The incoming bandwidth reaches 20 Mbps
4 Channels two-way talk over coaxial cable allows for seamless communication between the camera, Client and recorder
4 Channels IMD+ for analog channels which allows the device to trigger accurate alarms for humans and vehicles
4 Channels AI Coding saves on storage and bandwidth while maintaining the details of targets in videos
Instastream, H.265, H.264+, H.264 dual stream video compression
- Mobile Software
- iCMOB, gCMOB
- CMS Software
- KVMS Pro Lite
- Processor
- Industrial-grade processor
- Operating System
- Embedded Linux
- User Interface
- Web, Local GUI
- IMD+ by DVR
- 4 Channels: Secondary filtering for human and vehicle, reducing false alarms caused by leaves, rain and lighting condition change
- IMD By Camera
- 5 Channels
- Analog Camera Input
- 4 BNC ports, Supports HDCVI/AHD/TVI/CVBS autodetect
- Camera Input
- 1. CVI: 1080p@25/30fps
- 720p@50/60fps
- 720p@25/30fps 2. TVI: 1080p@25/30fps
- 720p@25/30fps 3. AHD: 1080p@25/30fps
- 720p@25/30fps
- IP Camera Input
- Up to 5 Channels of IPC access 1 IP channel by default + 4 channels (Analog channels are converted to IP channels) Incoming bandwidth: 20 Mbps, recording bandwidth: 20 Mbps and outgoing bandwidth: 20 Mbps *After IP extension is enabled, the AI Function (IMD) will be disabled
- Stream Capability
- Dual stream
- Video Frame Rate
- Main stream: 1080N/720p/960H/D1/CIF@(1fps–25/30fps) Sub stream: CIF@(1fps–15fps)
- Bit Rate
- 32 kbps–4096 kbps
- Audio Sample Rate
- 8 kHz, 16 bit
- Audio Bit Rate
- 64 kbps
- Video Output
- 1 HDMI: 1920 × 1080, 1280 × 1024, 1280 × 720 1 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720
- Video Display Split
- When IP extension mode not enabled: 1/4 When IP extension mode enabled: 1/4/6
- Video Compression
- AI Coding, Instastream, H.265, H.264+, H.264
- Audio Compression
- G.711a, G.711u, PCM, AAC
- Protocols
- HTTPS, TCP/IP, IPv4, IPv6, RTSP, UDP, NTP, DHCP, DNS, SMTP, UPnP, IP Filter, FTP, DDNS, SNMP, Alarm Server, InstaOn, Auto Connect, IP Search, ONVIF 24.06 (Profile T, Profile S, Profile G), CGI, SDK
- Smart Phone
- iOS, Android
- Browser
- Chrome, IE, Safari, Edge, Firefox
- Recording Playback
- 1/4
- Backup Mode
- USB device and network
- Playback Mode
- Instant playback, General playback, Event playback, Tag playback, Smart playback
- Intelligent Alarm
- IMD
- Alarm Linkage
- Record, Snapshot (panoramic), IPC external alarm output, Audio, Buzzer, Log, Preset, Email
- Audio Input
- 1 Channel RCA 4 Channel BNC (Coaxial Audio)
- Two-way Talk
- Coaxial two-way talk: 4 Channel BNC Local and network user two-way talk: Shares the same audio input with the first channel
- Disk Interface
- 1 SATA port, up to 6 TB. This limit varies depending on the environment temperature
- Interface Ports
- 2 USB (2 rear USB 2.0 ports)
- Ethernet
- 1 (10/100 Mbps Ethernet port, RJ-45)
- Power Supply
- 12 VDC, 1.5 A
- Power Consumption
- <7 W (without HDD)
- Operating Temperature
- –10°C to +45°C (+14°F to +113°F)
- Operating Humidity
- 10%–90% (RH), non-condensing
- Dimension
- 197 mm × 204.3 mm × 41.5 mm
- Weight
- 540g
