Supports HDCVI/AHD/TVI/CVBS/IP video inputs
Max 6 channels IP camera inputs, each channel up to 6MP; Max 32Mbps Incoming Bandwidth
Supports Full-channel AI-Instastream
Support 1 SATA HDD up to 16TB Each, 2 USB Ports
Up to 4 channels video stream (analog channel) SMD Plus.
1 HDMI / 1 VGA Simultaneous Video Output
AI Instastream/Instastream/H.265 dual-stream video compression
- Mobile Software
- iCMOB, gCMOB
- CMS Software
- KVMS Pro Lite
- Processor
- Industrial-grade processor
- Operating System
- Embedded LINUX
- IP Camera Input
- Up to 6 channels of IPC access 2 IP channels by default + 4 channels (analog channels are converted to IP channels) incoming bandwidth: 32 Mbps, recording bandwidth: 32 Mbps and outgoing bandwidth: 32 Mbps *After IP channels are added beyond the existing channels, the AI Function (SMD) will be disabled
- Two-way Talk
- Support (share the same audio input with the first channel)
- User Interface
- Web; Local GUI
- SMD Plus by DVR
- 4-channel: Secondary filtering for human and motor vehicle, reducing false alarms caused by leaves, rain and lighting condition change
- Camera Input
- 1. CVI: 5 MP, 4 MP, 1080p@25/30 fps, 720p@50/60 fps, 720p@25/30 fps. 2. TVI: 5 MP, 4 MP, 1080p@25/30 fps, 720p@25/30 fps. 3. AHD: 5 MP, 4 MP, 1080p@25/30 fps, 720p@25/30 fps. 4. CVBS: PAL/NTSC
- Resolution
- 5M-N; 4M-N; 1080p; 1080N; 720p; 960H; D1; CIF
- Video Output
- 1 HDMI, 1 VGA HDMI/VGA: 1920 × 1080, 1280 × 1024, 1280 × 720
- Video Compression
- H.265; H.264+; H.264+; H.264
- Encode Strategy
- AI Instatream; Instastream
- Video Recording
- Main stream: All channel 5M-N (1 fps–10 fps)
- 4M-N/1080p (1 fps–15 fps)
- 1080N/720p/960H/ D1/CIF (1 fps–25/30 fps) Sub stream: D1/CIF (1 fps–15 fps)
- Video Display Split
- 1/4
- Bit Rate
- 32 kbps–6144 kbps per channel
- Audio Output
- 1 channel, RCA
- Audio Input
- 1-channel RCA 4-channel BNC (Coaxial Audio)
- Audio Sample Rate
- 8KHz, 16 bit Per Channel
- Audio Bit Rate
- 64Kbps Per Channel
- Audio Compression
- G.711A, G.711U, PCM
- General Alarm
- Motion detection, video loss, tampering
- Anomaly Alarm
- No disk, disk error, low space, offline, ip conflict, MAC conflict
- Alarm Linkage
- Record, snapshot (panoramic), IPC external alarm output, access controller, voice prompt, buzzer, log, preset, email
- Smart Phone
- iPhone, iPad, Android Phone
- Hard Disk
- 1 SATA port, up to 16 TB. The maximum HDD capacity varies with environment temperature.
- Playback Recording
- 1/4 Ch.
- Record Mode
- General, motion detection, alarm, POS
- Search Mode
- Time/Date, Alarm, MD & Exact search (accurate to second)
- Playback Mode
- Instant playback, general playback, event playback, tag playback
- Backup Mode
- USB Device and Network
- Interface Ports
- 2 USB Ports (USB 2.0)
- Network Mode
- Single-address mode
- Ethernet
- 1 Port (10/100 Mbps Ethernet port, RJ-45)
- Protocols
- HTTP
- HTTPS
- TCP/IP
- IPv4
- RTSP
- UDP
- SMTP
- NTP
- DHCP
- DNS
- DDNS
- InstaOn cloud
- ONVIF 21.06
- CGI Conformant
- Power Supply
- DC12V/1.5A
- Power Consumption
- <4W (without HDD)
- Operating Temperature
- -10 °C to +55 °C (+14 °F to +131 °F)
- Operating Humidity
- 0%–90% (RH)
- Dimension
- 197.0mm × 203.4 mm × 41.5 mm (7.76'' × 8.01'' × 1.63'') (W × D × H)
- Weight
- 0.55kg
