Supports 4-ch 2MP analog cameras and 4-ch 2MP IP cameras input
Support Instastream/ H.265 video compression
Aviation connectors adopted
Support 1 HDD and 1 SD card, 3 USB Ports (2.0)
Supports DSM/ADAS/BSD
Support GPS and 3G/4G
Support Penta-Brid (HDCVI/AHD/TVI/CVBS/IP) video input
VGA/TV simultaneous video output
- Mobile Software
- EMSS Pro, iCMOB/gCMOB (Live view and Playback)
- CMS Software
- EMSS Pro, KVMS Pro (Live view and Playback)
- Processor
- High-performance industrial embedded micro-controller
- Frame Rate
- PAL: 1-25fps, NTSC: 1-30fps
- IP Camera Input
- 4 IP cameras, up to 1080P resolution (extendable via PoE switch)
- Video Compression
- H.265+, H.264
- Two-way Talk
- Supported
- Encode Strategy
- Instastream
- Video Resolution
- VGA: 800×600, Web: 1280×1024
- OSD
- Channel, time, GPS position, license plate
- Video Display Split
- 1/4/8
- Audio Compression
- G.711A/G.711U/PCM
- Audio Input
- 2 (with Built-in Mic camera)
- Video Output
- AV OUT x 1, VGA x 1
- Audio Output
- 1 aviation port for audio output, 1 audio talk output
- Alarm IN
- 8 channels for alarm input, 1 channel for pulse speed measuring
- Dual-Stream
- Supported (up to D1 encoding for sub stream)
- Alarm Out
- 2 channel of controllable 12V alarm output, digital quantity
- Playback
- 1, 4, 6
- Hard Disk
- 1, 2.5-inch HDDs (SATA) up to 2TB
- Image Quality Adjustment
- Image quality adjustable across six levels
- Backup Mode
- HDD, USB flash drive and network backup
- GPS
- Support
- Alarm Linkage
- Record, snapshot, local external alarm output, buzzer, log, screen prompt, tour
- Interface Ports
- Front panel: 2 × USB 2.0 Rear panel: 1 × USB 2.0 from EXTEND port, 2 Port RS232, 1 Port RS485, 1 TV Output, 1 Pulse Count
- BSD
- Blind Spot Detection
- Abnormal Alarm
- No HDD, HDD error, insufficient capacity, illegal login, ACC off, high temperature, rollover, battery low voltage, over speed, low speed, collision, tapid turn, rapid speedup, hard braking, low battery safety exception, network security exception
- Memory
- 1 SD card, Up to 256GB
- Gyroscope
- Supports event detection and alarm such as rollover, collision, rapid speedup/slowdown/turn
- Ethernet
- Front panel: 1 × 10M/100M RJ45 Rear panel: 1 × 10M/100M 6-pin aviation connector
- Operating Temperature
- -30 °C to +70°C (–22 °F to +158 °F)
- Dimension
- 1 DIN Front panel: 190 mm × 60 mm (7.5’×2.4’) Rear panel: 180 mm × 50 mm (7.1’×2.0’)
- Power Source
- DC 6-36V with the built-in UPS (Enables system protection in normal power cut-off and in Under voltage of vehicle battery.)
- Power Consumption
- 8.4W (without peripheral) Low power consumption: < 0.1W
- Weight
- 2.83Kg (with packages)
