Supports 4-ch 2MP analog cameras and 4-ch 2MP IP cameras input
Support Instastream/ H.265 video compression
Support Penta-Brid (HDCVI/AHD/TVI/CVBS/IP) video input
Aviation connectors adopted
Support 1 HDD and 1 SD card, 3 USB Ports (2.0)
Supports DSM/ADAS/BSD
VGA/TV (Din Connector) simultaneous video output
- Mobile Software
- EMSS Pro, iCMOB/gCMOB (Live view and Playback)
- CMS Software
- EMSS Pro, KVMS Pro (Live view and Playback)
- Processor
- High-performance industrial embedded micro-controller
- Operating System
- Embedded LINUX
- Two-way Talk
- Supported
- Operation Interface
- WEB, AV, VGA
- IP Camera Input
- 2 IP cameras, up to 1080P resolution (extendable via PoE switch)
- Video Output
- AV OUT x 1, VGA x 1
- Video Compression
- H.265+, H.264
- Encode Strategy
- Instastream
- Video Frame Rate
- PAL: 1-25fps, NTSC: 1-30fps
- Video Resolution
- 1020 x 768
- Video Display Split
- 1/4/8/9
- OSD
- Channel, time, GPS position, license plate
- Analog Camera Input
- 2 HDCVI/AHD/TVI/CVBS cameras, up to 1080P resolution (Audio input is not supported when connecting AHD/TVI/CVBS cameras)
- Dual-Stream
- Supported (up to D1 encoding for sub stream)
- Image Quality Adjustment
- mage quality adjustable across six levels
- Audio Compression
- G.711A/G.711U/PCM
- Audio Input
- 2 (with Built-in Mic camera)
- Audio Output
- 1 aviation port for audio output, 1 audio talk output
- Alarm Output
- 1 channel of controllable 12V alarm output, digital quantity
- SD Card
- 1 SD card, Up to 256GB
- Hard Disk
- 1, 2.5-inch HDDs (SATA) up to 2TB
- ADAS
- Alerts for forward collision, lane departure and vehicles distance too close
- Heat Dissipation
- Built-in fan cooling
- Abnormal Alarm
- No HDD, HDD error, insufficient capacity, illegal login, ACC off, high temperature, rollover, battery low voltage, over speed, low speed, collision, tapid turn, rapid speedup, hard braking, low battery safety exception, network security exception
- Gyroscope
- Supports event detection and alarm such as rollover, collision, rapid speedup/slowdown/turn
- Recording Playback
- TV Display: 1 split, Web: 4 split (max)
- Backup Mode
- HDD, USB flash drive and network backup
- Interface Ports
- Front panel: 2 × USB 2.0 Rear panel: 1 × USB 2.0 from EXTEND port, 2 Port RS232, 1 Port RS485, 1 TV Output, 1 Pulse Count
- Power Supply
- DC 6-36V with the built-in UPS (Enables system protection in normal power cut-off and in Under voltage of vehicle battery.)
- Network Port
- Front panel: 1 × 10M/100M RJ45, Rear panel: 1 × 10M/1000M 6-pin aviation connector
- Power Consumption
- 8.4W (without peripheral)
- Operating Temperature
- -30 °C to +50°C (–22 °F to +158 °F)
- Operating Humidity
- 10 ~ 90%
- Dimension
- 1 DIN Front panel: 190 mm × 60 mm (7.5’×2.4’) Rear panel: 180 mm × 50 mm (7.1’×2.0’) Depth:190 mm (7.5’)
- Net Weight
- 2.83Kg (with packages)
