Supports 4-ch 2MP analog cameras and 1-ch 2MP IP cameras input
Support Instastream/ H.265 video compression
Aviation connectors adopted
Support 2 SD cards (up to 256GB for each), 2 USB Ports (2.0)
Supports DSM/ADAS/BSD
- Mobile Software
- EMSS Pro, iCMOB/gCMOB (Live view and Playback)
- CMS Software
- EMSS Pro, KVMS Pro (Live view and Playback)
- Processor
- High-performance industrial embedded micro-controller
- Operating System
- Embedded LINUX
- Two-way Talk
- Supported
- Operation Interface
- WEB, AV
- IP Camera Input
- 1 IP camera, up to 1080P resolution
- Video Output
- AV OUT×2
- Video Compression
- H.265+, H.264, Smart H.264
- Encode Strategy
- Instastream
- Video Frame Rate
- PAL: 1-25fps, NTSC: 1-30fps
- Video Resolution
- 800 x 600
- Video Display Split
- 1/4/6/9
- OSD
- Channel, time, GPS position, license plate
- Analog Camera Input
- 1 HDCVI/AHD/TVI/CVBS cameras, up to 1080P resolution (Audio input is not supported when connecting AHD/TVI/CVBS cameras)
- Dual-Stream
- Supported (up to D1 encoding for sub stream)
- Image Quality Adjustment
- Image quality adjustable across six levels
- Audio Compression
- G.711A/G.711U/PCM
- Audio Input
- 1 channels PoE audio input
- Audio Output
- 1 aviation port for audio output, 1 audio talk output
- Alarm Input
- 4 channels for alarm input, 1 channel for pulse speed measuring
- Alarm Output
- 1 channel of controllable 12V alarm output, digital quantity
- SD Card
- 1 SD card, Up to 256GB
- Recording Mode
- Auto, Manual, motion detection, schedule, alarm Record alarm > alarm > motion detection > schedule
- Abnormal Alarm
- No HDD, HDD error, insufficient capacity, illegal login, ACC off, high temperature, rollover, battery low voltage, over speed, low speed, collision, tapid turn, rapid speedup, hard braking, low battery safety exception, network security exception
- Recording Playback
- 1, 4, 6
- Backup Mode
- HDD, USB flash drive
- Interface Ports
- Front panel: 1 × USB 2.0 Rear panel: 1 × USB 2.0 from EXTEND port, 1 Port RS232, 1 Port RS485, 1 TV Output, 1 Pulse Count
- Power Supply
- DC 6-36V with the built-in UPS (Enables system protection in normal power cut-off and in Under voltage of vehicle battery.)
- Network Port
- 1 × 10M/1000M RJ45 (rear panel)
- Power Consumption
- 6.7W (without peripheral), Low power consumption: < 0.1W
- Operating Temperature
- -30 °C to +60°C (–22 °F to +158 °F)
- Operating Humidity
- 10 ~ 90%
- Dimension
- 138 mm × 160 mm × 49 mm
- Net Weight
- 2.83Kg (with packages)
