Supports HDCVI, AHD, TVI, CVBS and IP video input
Supports up to 5 Channel IP camera input and each channel can be up to 2MP
The incoming bandwidth reaches 20 Mbps
4 Channel two-way talk over coaxial cable allows for seamless communication between the camera, Client and recorder
Instastream, H.265, H.264 , H.264 dual-stream video compression
- Mobile Software
- iCMOB, gCMOB
- Processor
- Industrial-grade processor
- Operating System
- Embedded Linux
- Analog Camera Input
- 4 BNC ports, Supports HDCVI/AHD/TVI/CVBS autodetect
- IP Camera Input
- Up to 5 Channels of IPC access 1 IP Channel by default + 4 Channels (analog Channels are converted to IP channels) Incoming bandwidth: 20 Mbps, recording bandwidth: 20 Mbps and outgoing bandwidth: 20 Mbps *After IP extension is enabled, the AI Function (SMD) will be disabled.
- Two-way Talk
- Coaxial two-way talk: 4 Channel BNC Local and network user two-way talk: Shares the same audio input with the first channel
- User Interface
- Web, Local GUI
- Video Output
- 1 HDMI: 1920 × 1080, 1280 × 1024, 1280 × 720; 1 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720
- Abnormality Alarm
- Error (No disk, Disk error, Low space, Low quota space, Network disconnection, IP conflict, MAC conflict), Video loss, Video tampering, Camera offline
- SMD By Camera
- 4 Channels
- Camera Input
- 1. CVI: 1080p@25/30 fps, 720p@50/60 fps, 720p@25/30 fps 2. TVI: 1080p@25/30 fps, 720p@25/30 fps 3. AHD: 1080p@25/30 fps, 720p@25/30 fps
- stream Capability
- Dual stream
- Video Frame Rate
- Main stream: 1080N/720p/960H/D1/CIF@(1 fps–25/30 fps) Sub stream: CIF@(1 fps–15 fps)
- Video Display Split
- When IP extension mode not enabled: 1/4 When IP extension mode enabled: 1/4/6
- Bit Rate
- 32 kbps–4096 kbps
- Video Compression
- AI Coding, Instastream, H.265, H.264+, H.264
- Protocols
- HTTPS, TCP/IP, IPv4, IPv6, RTSP, UDP, NTP, DHCP, DNS, SMTP, UPnP, IP Filter, FTP, DDNS, SNMP, Alarm Server, InstaOn, Auto connect, ONVIF (Profile T, Profile S, Profile G), CGI, SDK
- Audio Input
- 1 Channel RCA, 4 Channel BNC (Coaxial Audio)
- Disk Interface
- 1 SATA port, up to 6 TB. This limit varies depending on the environment temperature
- Smart Phone
- iOS, Android
- Browser
- Chrome, IE, Safari, Edge, Firefox
- Recording Playback
- 1/4
- Playback Mode
- Instant playback, General playback, Event playback, Tag playback, Smart playback
- Backup Mode
- USB device and network
- Interface Ports
- 2 USB (2 rear USB 2.0 ports)
- Ethernet
- 1 (10/100 Mbps Ethernet port, RJ-45)
- Power Supply
- 12 VDC, 1.5
- Power Consumption
- <7 W (without HDD)
- Operating Temperature
- –10°C to +45°C (+14°F to +113°F)
- Operating Humidity
- 10%–90% (RH), non-condensing
- Storage Temperature
- –10°C to +45°C (+14°F to +113°F)
- Dimensions
- 197.0 mm × 204.3 mm × 41.5 mm
