Supports HDCVI/AHD/TVI/CVBS/IP video inputs
Max 10 channels IP camera inputs, each channel up to 6MP; Max 40Mbps Incoming Bandwidth
Support 1 SATA HDD up to 6TB, 2 USB Ports
1 HDMI / 1 VGA Simultaneous Video Output
Instastream/H.265/H.264+/H.264 video compression
- Mobile Software
- iCMOB, gCMOB
- CMS Software
- KVMS Pro
- Processor
- Embedded processor
- IP Camera Input
- 8+2 channels, each channel up to 6MP
- Operating System
- Embedded LINUX
- Two-way Talk
- Reuse audio in/out, RCA
- User Interface
- GUI
- Video Output
- 1 HDMI, 1 VGA
- Video Input
- 8 channel, BNC
- Video Compression
- Instastream/H.265/H.264+/H.264
- Video Display Split
- 1/4/8/9
- Video Loss
- supports
- Video Recording
- Main Stream: the 1st channel 1080N/720P(1~25/30fps), others 1080N/720P(1~15fps)
- 960H/D1/CIF(1~25/30fps)
- Sub stream: CIF/QCIF (1~7fps)
- Video Resolution
- 1920×1080, 1280×1024, 1280×720, 1024x76
- Resolution
- 1080N, 720P, 960H, D1, HD1, BCIF, CIF, QCIF
- Bit Rate
- 32 kbps–4096 kbps per channel
- Audio Compression
- G.711A, G.711U, PCM
- Audio Input
- 1 channel, RCA
- Audio Output
- 1 channel, RCA
- Audio Sample Rate
- 8KHz, 16 bit Per Channel
- Audio Bit Rate
- 64Kbps Per Channe
- Record Interval
- 1~60 min (default: 60 min), Pre-record: 1~30 sec, Post record: 10~300 sec
- Trigger Events
- Recording, PTZ, Tour, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips
- OSD
- Camera title, Time, Video loss, Camera lock, Motion detection, Recording
- Motion Detection
- Support
- Playback
- 1/4/9 Ch.
- Camera Blank
- Support
- Recording Playback
- Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup, selection, Digital zoom
- Search Mode
- Time/Date, Alarm, MD & Exact search (accurate to second)
- Recording Mode
- Manual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop
- Backup Mode
- USB Device
- Hard Disk
- 1 SATA port, up to 6TB capacity
- User Account
- 128 users
- Smart Phone
- iPhone, iPad, Android Phone
- Ethernet
- 1 RJ-45 port (100Mbps)
- Interface Ports
- 2 USB Ports (USB 2.0)
- Protocols
- HTTP
- HTTPS
- TCP/IP
- IPv4/IPv6
- UPnP
- RTSP
- UDP
- SMTP
- NTP
- DHCP
- DNS
- IP Filter
- DDNS
- FTP
- Alarm Server
- InstaOn
- IP Search, ONVIF 16.12, CGI Conformant
- Power Supply
- DC12V/1.5A
- Playback Function
- Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup, selection, Digital zoom
- Power Consumption
- <10W (without HDD)
- Dimension
- 198 mm × 202.9 mm × 41.5 mm
- Working Temperature
- -10°C ~ +45°C (+14°F ~ +113°F), 10 ~ 90% (RH)
- User Access
- 128 users
- Storage Temperature
- -20°C ~ +70°C (-4°F ~ +158°F), 0 ~ 90% (RH)
- Net Weight
- 0.55kg (without HDD)
