Supports HDCVI/AHD/TVI/CVBS/IP video inputs
Max 12 channels IP camera inputs, each channel up to 6MP; Max 64Mbps Incoming Bandwidth
Supports Full-channel AI-Coding
Instastream/H.265 dual-stream video compression
Up to 8 channels video stream (analog channel) SMD Plus
Support 1 SATA HDD up to 6TB, 2 USB Ports
1 HDMI / 1 VGA Simultaneous Video Output
- Mobile Software
- iCMOB, gCMOB
- CMS Software
- KVMS Pro
- Processor
- Embedded processor
- Operating System
- Embedded LINUX
- IP Camera Input
- 8+4 channels, each channel up to 6MP
- Two-way Talk
- Reuse audio in/out, RCA
- User Interface
- GUI
- Video Output
- 1 HDMI, 1 VGA
- Video Resolution
- 1920×1080, 1280×1024, 1280×720
- Video Compression
- AI Instastream/Instastream/H.265/H.264+/H.264
- Video Recording
- Main stream: All channel 5M-N (1 fps–10 fps)
- 4M-N/1080p (1 fps–15 fps)
- 1080N/720p/960H D1/CIF (1 fps–25/30 fps)
- Video Display Split
- 1/4/8/9
- Resolution
- 5M-N; 4M-N; 1080P; 1080N; 720P; 960H; D1; CIF
- Bit Rate
- 32 kbps–6144 kbps per channel
- Video Channel
- 4 channel, BNC
- Audio Compression
- G.711A, G.711U, PCM
- Audio Input
- 1 channel, RCA
- Audio Output
- 1 channel, RCA
- Motion Detection
- Support
- Video Loss
- Support
- Smart Phone
- iPhone, iPad, Android Phone
- Hard Disk
- 1 SATA port, up to 6TB
- Camera Blank
- Support
- Trigger Events
- Recording, PTZ, Tour, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips
- Recording Mode
- Manual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop
- Search Mode
- Time /Date, Alarm, MD and Exact Search (accurate to second)
- Backup Mode
- USB Device/Network
- Playback
- Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file,Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup, selection, Digital zoom
- Max User Account
- 128 users
- Record Interval
- 1~60 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec
- Ethernet
- 1 RJ-45 port (100Mbps)
- Interface Ports
- 2 USB Ports (USB 2.0)
- Protocols
- HTTP
- HTTPS
- TCP/IP
- IPv4/IPv6
- Wi-Fi
- 3G/4G
- SNMP
- UPnP
- RTSP
- UDP
- SMTP
- NTP
- DHCP
- DNS
- IP Filter
- PPPoE
- DDNS
- FTP
- Alarm Server
- InstaOn
- IP Search, ONVIF 16.12, CGI Conformant
- Power Supply
- DC12V/1.5A
- Power Consumption
- <7W (without HDD)
- Working Temp
- -10°C ~ +45°C (+14°F ~ +113°F), 0 ~ 90% RH
- Dimension
- 198.3mm × 203.4mm × 41.5mm
- Weight
- 0.57kg (without HDD)
