English
Up to 8 Ch IP Camera Input
Max 12 channels IP camera inputs, each channel up to 6MP
Max 64Mbps Incoming Bandwidth
Supports Full-channel AI Instastream
1 HDMI / 1 VGA Simultaneous Video Output
Support 1 SATA HDD up to 16TB Each, 2 USB Ports
Up to 8 channels video stream (analog channel) SMD Plus
- Mobile Software
- iCMOB, gCMOB
- CMS Software
- KVMS Pro Lite
- Processor
- Industrial-grade processor
- Operating System
- Embedded LINUX
- Analog Camera Input
- 8 channels, BNC: adaptive access by default HDCVI, AHD, TVI and CVBS access can be configured
- Camera Input
- 1. CVI: 5 MP, 4 MP, 1080p@25/30 fps, 720p@50/60 fps, 720p@25/3 0fps. 2. TVI: 5 MP, 4 MP, 1080p@25/30 fps, 720p@25/30 fps. 3. AHD: 5 MP, 4 MP, 1080p@25/30 fps, 720p@25/30 fps. 4. CVBS: PAL/NTSC
- IP Camera Input
- Up to 12 channels of IPC access 4 IP channels by default + 8 channels (analog channels are converted to IP channels) incoming bandwidth: 64 Mbps, recording bandwidth: 64 Mbps and outgoing bandwidth: 64 Mbps After IP channels are added beyond the existing channels, the AI Function (SMD) will be disabled
- User Interface
- Web; GUI
- Video Input
- 08 channel, BNC
- Video Output
- 1 HDMI, 1 VGA HDMI/VGA: 1920 × 1080, 1280 × 1024, 1280 × 720
- SMD Plus by DVR
- 8-channel: Secondary filtering for human and motor vehicle, reducing false alarms caused by leaves, rain and lighting condition change
- Video Compression
- H.265+, H.264+, H.264
- Encoding Capacity
- Main Stream: All channel 5M-N@(1 fps–10 fps), 4M-N/1080p@(1 fps– 15 fps) 1080N/ 720p/960H/D1/CIF@(1 fps–25/30 fps), Sub stream: D1/CIF (1 fps–15 fps
- Encode Strategy
- AI Instastream, Instastream
- Network Mode
- Single-address mode
- Video Display Split
- When IP extension mode not enabled: 1/4/8/9/16, When IP extension mode enabled: 1/4/8/9/16
- Bit Rate
- 32 kbps–6144 kbps
- Audio Compression
- G.711A, G.711U, PCM
- Smart Phone
- iPhone, iPad, Android Phone
- Audio Sample Rate
- 8 KHz, 16 bit per channel
- Audio Bit Rate
- 64 kbps per channel
- General Alarm
- Motion detection, video loss, tampering
- Alarm Linkage
- Record, snapshot (panoramic) local alarm output, IPC external alarm output, access controller, audio, buzzer, log, preset, email
- Browser
- Chrome IE9 or later Firefox
- Recording Playback
- Instant playback, general playback, event playback, tag playback
- Playback
- 1/4/8/9 Ch.
- Backup Mode
- USB Device/Network
- Interface Ports
- 2 USB Ports(2.0)
- Ethernet
- 1 (10/100 Mbps Ethernet port, RJ-45)
- Protocols
- HTTP, HTTPS, TCP/IP, IPv4, RTSP, UDP, SMTP, NTP, DHCP, DNS, DDNS, FTP, ONVIF 21.06; CGI Conformant
- Power Supply
- DC12V/15A
- Power Consumption
- <7 W
- Operating Temperature
- –10 °C to +55 °C (+14 °F to +131 °F)
- Operating Humidity
- 0%–90% (RH)
- Dimension
- 198.3 mm × 203.4 mm × 41.5 mm
- Weight
- 0.57 kg without HDD
