English
Supports HDCVI/AHD/TVI/CVBS/IP video inputs
Max 16 channels IP camera inputs, each channel up to 8MP; Max 128Mbps incoming bandwidth
Supports Full-channel AI Instastream
Support 1 SATA HDD up to 16TB Each, 3 USB Ports
Up to 8 channels video stream (analog channel) SMD Plus
Up to 8 channels video stream (analog channel) perimeter protection
Up to 2 channels video stream (analog channel) human face recognition
AI Instastream/Instastream/H.265 dual-stream video compression
Perimeter Performance of AI by DVR (Number of Channels): Advanced Model: 2 channels, 10 IVS for each channel General Model: 8 channels, 10 IVS for each channel
Face Detection Performance of AI by DVR (Number of Channels): 2 channels (up to 12 face images each channel)
- Mobile Software
- iCMOB, gCMOB
- CMS Software
- KVMS Pro
- Processor
- Industrial-grade processor
- Operating System
- Embedded LINUX
- IP Camera Input
- Up to 16 channels of IPC access 8 IP channels by default + 8 channels (analog channels are converted to IP channels) incoming bandwidth: 128 Mbps, recording bandwidth: 128 Mbps and outgoing bandwidth: 128 Mbps *After IP channels are added beyond the existing channels, the AI Function (IVS, SMD, FACE) will be disabled.
- Camera Input
- 1. CVI: 4K@25/30 fps
- 6MP@20 fps
- 5 MP@20 fps
- 5MP@25 fps
- 4MP@25/30 fps
- 1080p@25/30 fps
- 720p@25/30 fps
- 720p@50/60 fps.2. TVI: 4K@15 fps
- 5MP@20fps
- 4MP@25/30 fps
- 3MP@25/30 fps
- 1080p@25/30 fps
- 720p@25/30 fps.3. AHD: 4K@15 fps
- 5MP@20 fps
- 4MP@25/30 fps
- 3MP@25/30 fps
- 1080p@25/30 fps
- 720p@25/30 fps
- Two-way Talk
- Support (share the same audio input with the first channel)
- User Interface
- Web; Local GUI
- SMD Plus by DVR
- 8 channels: Secondary filtering for human and motor vehicle , reducing false alarms caused by leaves, rain and lighting condition change
- Face Attributes
- Gender; age group; glasses; expressions; face mask; beard
- Video Input
- 8 channel, BNC
- Video Output
- 1 HDMI, 1 VGA HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720 *Simultaneous/heterogeneous video sources output for VGA and HDMI is configurable
- Video Compression
- H.265+; Smart H.264+; H.264
- Encode Strategy
- AI Instastream; Instastream
- Video Streaming
- Main stream: 4K@(1fps-7fps)
- 6 MP@(1fps-10fps)
- 5 MP@(1fps-12fps)
- 4K-N, 4 MP, 3 MP@ (1fps-15fps)
- 4M-N, 1080p, 720p, 960H, D1,CIF@(1fps–25/30fps)
- Sub stream: 960H@(1fps– 15fps)
- D1/CIF@(1 fps–25/30fps)
- Video Display Split
- 1/4/8/9
- Audio Input
- 1-channel RCA, 8-channel BNC (Coaxial Audio)
- Bit Rate
- 32 kbps–6144 kbps
- Audio Output
- 1 channel, RCA
- Audio Sample Rate
- 8KHz, 16 bit Per Channel
- Audio Bit Rate
- 64Kbps Per Channel
- Audio Compression
- G.711A, G.711U, PCM
- General Alarm
- Motion detection; video loss; tampering
- Alarm Linkage
- Record
- snapshot (panoramic)
- IPC external alarm output
- access controller
- voice prompt
- buzzer
- log
- preset
- Smart Phone
- iPhone, iPad, Android Phone
- Hard Disk
- 1 SATA port, up to 16TB capacity disk. The maximum HDD capacity varies with environment temperature.
- Recording Playback
- 1/4/9
- Recording Mode
- General, motion detection; intelligent; alarm; POS
- Playback
- Instant playback, general playback, event playback, tag playback, smart playback (face and motion detection)
- Backup Mode
- USB Device/Network
- Interface Ports
- 2 (1 front USB 2.0 port, 1 rear USB 3.0 port), 1 RS485 Port
- Browser
- Chrome, IE9 or later, Firefox
- Network Mode
- Single-address mode
- Ethernet
- 1 (10/100/1000 Mbps Ethernet port, RJ-45)
- Protocol
- IPv4/IPv6, HTTP, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS,Bonjour, ONVIF Ver. 2.0
- Power Supply
- DC 12V, 2A
- Power Consumption
- <10 W (without HDD)
- Operating Humidity
- 10%–90% (RH)
- Operating Temperature
- -10°C ~ +55°C (14°F ~ +131°F)
- Dimension
- 260.0 mm × 237.9 mm × 47.6 mm
