Supports HDCVI, AHD, TVI, CVBS and IP video input
Supports up to 10-channel IP camera input and each channel can be up to 6 MP.
The incoming bandwidth reaches 40 Mbps
8 Channel two-way talk over coaxial cable allows for seamless communication between the camera, client and recorder
Instastream, H.265, H.264+ H.264 dual-stream video compression
- Mobile Software
- iCMOB, gCMOB
- Processor
- Industrial-grade processor
- Operating System
- Embedded Linux
- Analog Camera Input
- BNC ports, supports HDCVI/AHD/TVI/CVBS autodetect
- IP Camera Input
- Up to 10 channels of IPC access 2 IP channels by default + 8 channels (analog channels are converted to IP channels) Incoming bandwidth: 40 Mbps, recording bandwidth: 40 Mbps and outgoing bandwidth: 40 Mbps *After IP extension is enabled, the AI Function (SMD) will be disabled.
- Two-way Talk
- Coaxial two-way talk: 8 Channel BNC Local and network user two-way talk: Shares the same audio input with the first channel
- User Interface
- Web, Local GUI
- Video Output
- 1 HDMI: 1920 × 1080, 1280 × 1024, 1280 × 720; 1 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720
- Abnormality Alarm
- Error (No disk, Disk error, Low space, Low quota space, Network disconnection, IP conflict, MAC conflict), Video loss, Video tampering, Camera offline
- SMD By Camera
- 10 Channels
- Camera Input
- 1. CVI: 1080p@25/30 fps
- 720p@25/30 fps. 2. TVI: 1080p@25/30 fps
- 720p@25/30 fps. 3. AHD: 1080p@25/30 fps
- 720p@25/30 fps
- stream Capability
- Dual stream
- Video Frame Rate
- Main stream: The 1st channel 1080N/720p@(1 fps–25/30 fps), others 1080N/720p@(1 fps–15 fps), 960H/D1/CIF@(1 fps–25/30 fps) Sub stream: CIF@(1 fps–7 fps)
- Video Display Split
- When IP extension mode not enabled: 1/4/8 When IP extension mode enabled: 1/4/8/9/16
- Record Mode
- General, Alarm, Motion detection
- Bit Rate
- 32 kbps–4096 kbps
- Video Compression
- AI Coding, Instastream, H.265, H.264+, H.264
- Protocols
- HTTPS, TCP/IP, IPv4, IPv6, RTSP, UDP, NTP, DHCP, DNS, SMTP, UPnP, IP Filter, FTP, DDNS, SNMP, Alarm Server, InstaOn, Auto connect, ONVIF (Profile T, Profile S, Profile G), CGI, SDK
- Audio Input
- 1-channel RCA, 8 Channel BNC (Coaxial Audio)
- SMD Plus by DVR
- Channels: Secondary filtering for human and vehicle, Reducing false alarms caused by leaves, Rain and lighting condition change
- Disk Interface
- 1 SATA port, up to 6 TB. This limit varies depending on the environment temperature
- Browser
- Chrome, IE, Safari, Edge, Firefox
- Recording Playback
- 1/4/
- Backup Mode
- USB device and network
- Interface Ports
- 2 USB (2 rear USB 2.0 ports)
- Ethernet
- 1 (10/100 Mbps Ethernet port, RJ-45)
- Power Supply
- 12 VDC, 1.5
- Power Consumption
- <7 W (without HDD)
- Operating Temperature
- –10°C to +45°C (+14°F to +113°F)
- Operating Humidity
- 10%–90% (RH), non-condensing
- Storage Temperature
- –10°C to +45°C (+14°F to +113°F)
- Dimension
- 197.0 mm × 204.3 mm × 41.5 mm
