Auto Adaptive HDCVI/AHD/TVI/CVBS/IP signals
Max 18 channels IP camera inputs, each channel up to 6MP
Max 64Mbps Incoming Bandwidth
Instastream/H.265 dual-stream Video Compression
Support 1 SATA HDD up to 16TB, 2 USB Ports
Up to 8 channels video stream (analog channel) SMD Plus
- Mobile Software
- iCMOB, gCMOB
- CMS Software
- KVMS Pro Lite
- Processor
- Industrial-grade processor
- Operating System
- Embedded LINUX
- IP Camera Input
- Up to 18 channels of IPC access 2 IP channels by default + 16 channels (analog channels are converted to IP channels) incoming bandwidth: 64 Mbps, recording bandwidth: 64 Mbps and outgoing bandwidth: 64 Mbps *After IP channels are added beyond the existing channels, the AI Function (SMD) will be disabled
- Two-way Talk
- Support (share the same audio input with the first channel)
- User Interface
- Web; GUI
- SMD Plus by DVR
- 8-channel: Secondary filtering for human and motor vehicle , reducing false alarms caused by leaves, rain and lighting condition change
- Video Output
- 1 HDMI, 1 VGA, HDMI/VGA: 1920 × 1080, 1280 × 1024, 1280 × 720
- Video Input
- 16 channel, BNC
- Encode Strategy
- AI Instastream/Instastream
- Video Compression
- H.265+/H.264+/H.264
- Camera Input
- 1. CVI: 1080p@ 25/30 fps, 720p@ 25/30 fps 2. TVI: 1080p@ 25/30 fps, 720p@ 25/30 fps 3. AHD: 1080p@ 25/30 fps, 720p@ 25/30 fps 4. CVBS: PAL/NTSC
- Video Display Split
- 1/4/8/9/16
- Encoding Capacity
- Main Stream: the 1st channel 1080N/720p (1 fps–25/30 fps), others 1080N/720p (1 fps–15 fps); 960H/D1/CIF(1 fps–25/30 fps) Sub stream: CIF (1 fps–7 fps)
- Bit Rate
- 32 kbps–6144 kbps
- Audio Input
- 1 channel RCA 16-channel BNC (Coaxial Audio)
- Audio Compression
- G.711A, G.711U, PCM
- General Alarm
- Motion detection, video loss, tampering
- Smart Phone
- iPhone, iPad, Android Phone
- Hard Disk
- 1 SATA port, up to 16 TB. The maximum HDD capacity varies with environment temperature
- Audio Sample Rate
- 8KHz, 16 bit Per Channel
- Playback
- 1/4/9 Ch.
- Audio Bit Rate
- 64Kbps Per Channel
- Playback Mode
- Instant playback, general playback, event playback, tag playback
- Backup Mode
- USB Device/Network
- Interface Ports
- 2 USB Ports (2.0)
- Ethernet
- 1 (10/1000 Mbps Ethernet port, RJ-45)
- Protocols
- HTTP; HTTPS; TCP/IP; IPv4; RTSP; UDP; SMTP; NTP; DHCP; DNS; DDNS; P2P, ONVIF 21.06; CGI Conformant
- Power Supply
- DC12V/1.5A
- Power Consumption
- <10W(without HDD)
- Working Temp
- -10°C ~ +55°C (+14°F ~ +113°F), 0 ~ 90% RH
- Dimension
- 260.0 mm × 231.4 mm × 47.6 mm
- Weight
- 1.42 kg
