Supports HDCVI/AHD/TVI/CVBS/IP video inputs
Max 18 channels IP camera inputs, each channel up to 6MP; Max 64 Mbps Incoming Bandwidth
Supports Full-channel AI-Coding
Instastream/H.265 video compression
Up to 8 channels video stream (analog channel) SMD Plus
Support 2 SATA HDD up to 10TB Each, 2 USB Ports
1 HDMI / 1 VGA simultaneous video output
- Mobile Software
- iCMOB, gCMOB
- CMS Software
- KVMS Pro
- Processor
- Embedded processor
- Operating System
- Embedded LINUX
- IP Camera Input
- 16+2/16 channels, each channel up to 6MP
- Two-way Talk
- Reuse audio in/out, RCA
- User Interface
- GUI
- Video Output
- 1 HDMI, 1 VGA
- Video Resolution
- 1920×1080, 1280×1024, 1280×720
- Video Recording
- Main Stream: 1st Ch. 1080N/720P(1~25/30fps), others 1080N/720P(1~15fps); 960H/D1/CIF (1~25/30fps) Sub steram:CIF(1~7fps)
- Resolution
- 1080N, 720P, 960H, D1, CIF
- Video Compression
- AI Instastream/Instastream/H.265/H.264+/H.264
- Video Display Split
- 1/4/8/9/16
- Video Channel
- 16 channels, BNC
- Audio Compression
- G.711A, G.711U, PCM
- Audio Output
- 1 channel, RCA
- Audio Input
- 1 channel, RCA
- Motion Detection
- Support
- Video Loss
- Supports
- Smart Phone
- iPhone, iPad, Android Phone
- Hard Disk
- 2 SATA port, up to 10TB Each
- Bit Rate
- 32Kbps ~ 4096Kbps Per Channel
- Trigger Events
- Recording, PTZ, Tour, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips
- Recording Mode
- Manual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop
- Search Mode
- Time/Date, MD & Exact search (accurate to second)
- Backup Mode
- USB Device/Network
- Playback
- Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup, selection, Digital zoom
- Max User Account
- 128 users
- Record Interval
- 1~60 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec
- Ethernet
- 1 RJ-45 port (100Mbps)
- Interface Ports
- 2 USB Ports (USB 2.0), 1 RS485 Port
- Protocols
- HTTP, HTTPS, TCP/IP, IPv4/IPv6, Wi-Fi, 3G/4G, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE, DDNS, FTP, Alarm Server, InstaOn, IP Search, ONVIF 16.12, CGI Conformant
- Power Supply
- DC12V/4A
- Power Consumption
- <10W(without HDD)
- Working Temp
- -10°C ~ +55°C (+14°F ~ +131°F), 10 ~ 90% RH
- Dimension
- 375mm × 289.4mm × 53mm
- Weight
- 1.61kg (without HDD)
