Supports HDCVI/AHD/TVI/CVBS/IP video inputs
Max 24 channels IP camera inputs, each channel up to 6MP
Supports Full-channel AI Instastream
Instastream/H.265 dual-stream video compression
Up to 16 channels video stream (analog channel) SMD Plus
Support 1 SATA HDD up to 16TB Each, 2 USB Ports
1 HDMI / 1 VGA Simultaneous Video Output
- Mobile Software
- iCMOB, gCMOB
- CMS Software
- KVMS Pro
- Processor
- Embedded processor
- Operating System
- Embedded LINUX
- IP Camera Input
- 16+8 channels, each channel up to 6MP
- Two-way Talk
- Reuse audio in/out, RCA
- User Interface
- GUI
- Video Output
- 1 HDMI, 1 VGA
- Video Resolution
- VGA: 1920 × 1080, 1280 × 1024, 1280 × 720 HDMI: 1920 × 1080, 1280 × 1024, 1280 × 720
- Video Compression
- AI Instastream/Instastream/H.265/H.264+/H.264
- Video Recording
- Main stream: All channel 5M-N (1 fps–10fps)
- 4M-N/1080p (1 fps–15fps)
- 1080N/720p/960H D1/CIF (1 fps–25/30fps) Sub Stream: D1/CIF (1 fps–15fps)
- Video Display Split
- 1/4/8/9/16
- Resolution
- 4M-N; 1080P; 1080N; 720P; 960H; D1; CIF
- Bit Rate
- 32 kbps–6144 kbps per channel
- Video Channel
- 16 channel, BNC
- Audio Compression
- G.711A, G.711U, PCM
- Audio Input
- 1 Ch., RCA (external) ; 16 Ch., BNC (coaxial)
- Audio Output
- 1 channel, RCA
- Motion Detection
- Support
- Video Loss
- Support
- Smart Phone
- iPhone, iPad, Android Phone
- Hard Disk
- 1 SATA port, up to 16TB Each
- Camera Blank
- Support
- Search Mode
- Time/Date, MD & Exact search (accurate to second)
- Backup Mode
- USB Device/Network
- Playback
- Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup, selection, Digital zoom
- Max User Account
- 128 users
- Record Interval
- 1~60 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec
- Ethernet
- 1 RJ-45 port (10/100/1000MB)
- Interface Ports
- 2 USB Ports (USB 2.0)
- Protocols
- TTP
- HTTPS
- TCP/IP
- IPv4/IPv6
- Wi-Fi
- 3G/4G
- SNMP
- UPnP
- RTSP
- UDP
- SMTP
- NTP
- DHCP
- DNS
- IP Filter
- PPPoE
- DDNS
- FTP
- Alarm Server
- InstaOn
- IP Search, ONVIF 16.12, CGI Conformant
- Power Supply
- DC12V/2A
- Power Consumption
- <12W (without HDD)
- Working Temp
- -10°C ~ +45°C (+14°F ~ +113°F), 0 ~ 90% RH
- Dimension
- 260.0 mm × 231.4 mm × 47.6 mm (W × D × H)
- Weight
- 0.93 kg (without HDD)
