Supports HDCVI/AHD/TVI/CVBS/IP video inputs
Support upto 8MP IP Camera
Instastream/ H.265 dual-stream video compression
Max 32 channels IP camera inputs, each channel up to 6MP; Max 128 Mbps incoming bandwidth
Support 1 SATA HDD up to 16TB, 2 USB Ports
1 HDMI / 1 VGA simultaneous video output
Up to 8 channels video stream (analog channel) Perimeter Protection.
Up to 16 channels video stream (analog channel) SMD Plus.
Up to 2 channels video stream (analog channel) human face recognition
Face Detection Performance of AI by DVR (Number of Channels): 4 Channels (up to 12 face images/s each channel)
- Mobile Software
- iCMOB, gCMOB
- Mobile Software
- iCMOB, gCMOB
- Processor
- Industrial-Grade Processor
- Analog Camera Input
- 16 BNC ports, supports HDCVI/AHD/TVI/CVBS auto-detect
- User Interface
- Web; Local GUI
- IP Camera Input
- Up to 32 channels of IPC access 16 IP channels by default + 16 channels (analog channels are converted to IP channels) incoming bandwidth: 128 Mbps, recording bandwidth: 128 Mbps and outgoing bandwidth: 128 Mbps *After IP channels are added beyond the existing channels, the AI Function (IVS, SMD, FACE) will be disabled
- Operating System
- Embedded Linux
- Camera Input
- 1. CVI: 4K@25/30 fps
- 6 MP@20 fps
- 5 MP@20 fps
- 5 MP@25 fps
- 4 MP@25/30 fps
- 1080p@25/30 fps
- 720p@25/30 fps
- 720p@50/60 fps.2. TVI: 4K@15 fps
- 5 MP@20 fps
- 4 MP@25/30 fps
- 3 MP@25/30 fps
- 1080p@25/30 fps
- 720p@25/30 fps.3. AHD: 4K@15 fps
- 5 MP@20 fps
- 4 MP@25/30 fps
- 3 MP@25/30 fps
- 1080p@25/30 fps
- 720p@25/30fps
- Two-way Talk
- Support (share the same audio input with the first channel)
- Video Output
- 1 HDMI, 1 VGA HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720 *Simultaneous/heterogeneous video sources output for VGA and HDMI is configurable
- Face Attributes
- Gender; Age group; Glasses; Expressions; Face mask; Beard
- Video Compression
- H.265+, H.265, H.264
- Frame Rate
- Main stream: 4K@(1fps-10fps)
- 6 MP@(1fps-10fps)
- 5 MP@(1fps-12fps)
- 4K-N, 4 MP, 3 MP@ (1fps-15fps)
- 4M-N, 1080p, 720p, 960H, D1,CIF@(1fps–25/30fps)
- Sub stream: 960H@(1fps– 15fps)
- D1/CIF@(1 fps– 25/30fps)
- Encode Strategy
- AI Instastream/ Instastream
- stream Capability
- Dual Stream
- Bit Rate
- 32 kbps–6144 kbps
- Audio Input
- 1-channel RCA ,16-channel BNC (Coaxial Audio)
- Audio Output
- 1 Channel RCA
- Audio Compression
- G.711a; G.711u; PCM
- Audio Sample Rate
- 8 kHz, 16 bit
- Hard Disk
- 1 SATA port, up to 8TB capacity for each disk. The maximum HDD capacity varies with environment temperature.
- Smart Phone
- iPhone, iPad, Android Phone
- Intelligent Alarm
- Face detection; Face recognition; Perimeter protection
- Recording Playback
- 1/4/9/16
- Browser
- Chrome, IE9 or later, Firefox
- Backup Method
- USB device and Network
- Playback
- Instant playback, General playback, Event playback, Tag playback, Smart playback (face and motion detection)
- Interface Ports
- 1 HDMI, 1 VGA, 1 RS485, 2 USB Ports( (1 front USB 2.0 port, 2 rear USB 3.0 port)
- Network Mode
- Single-address mode
- Ethernet
- 1 RJ-45 Port ((10/100/100Mbps)
- Protocols
- HTTP
- HTTPS
- TCP/IP
- IPv4
- RTSP
- UDP
- SMTP
- NTP
- DHCP
- DNS
- DDNS
- ONVIF 22.12(Profile T
- Profile S
- Profile G)
- CGI
- SDK
- Power Supply
- DC12V, 1Amp
- Power Consumption
- <15W (Without HDD)
- Operating Temperature
- -10 ~+50°C
- Operating Humidity
- 10%–90% (RH)
- Dimension
- 325 mm × 257.1 mm × 55.0 mm
- Weight
- 1.5Kg
