Max 320 Channel IP camera inputs
48 bays, SATA, Hot-Swap
Max 800 Mbps incoming/recording/forwarding bandwidth
Supports video stream direct storage mode and IPSAN storage mode
Supports N+M cluster
Supports Automatic Network Replenishment (ANR)
1+1 redundant 80PLUS platinum power supply
- Processor
- 64-bit high-performance multi-core processor
- Operating System
- Embedded Linux OS
- IP Camera Input
- 320 Channel
- User Interface
- Web (PCAPP)
- Network Mode
- NIC binding mode such as multiple-address mode, Load balance, Fault-tolerance, Link aggregation, etc
- N+M Cluster
- Support
- Video Compression
- Instastream, H.265, H.264+, H.264, MJPEG
- Audio Compression
- G.711A, G.711U, PCM, G726
- Disk Group
- Support
- General Alarm
- Motion detect, Tampering, IPC external alarm
- Abnormality Alarm
- IPC offline alarm, Storage error, HDD full, Video frame loss, SSD exception, IP conflict, MAC conflict, Login lock, Fan malfunction, No HDD, Network security exception, Power exception, Disk health exception, RAID exception, Storage pool exception, Temperature alarm, Share service
- Storage Pool
- Support
- iSCSI
- Supports client and Server
- Network Disk
- Supports client
- Browser
- Chrome, PCAPP, IE9 or higher, Firefox
- Multi-channel Playback
- Max. 16 Channel playback
- RAID
- RAID 0/1/5/6/10/50; (with enterprise-grade HDD)
- Video Direct Storage (Private Protocol)
- Incoming: 320 Channel (bandwidth: 800 Mbps), Recording: 320 Channel (bandwidth: 800 Mbps), Outgoing: 320 Channel (bandwidth: 800 Mbps), Playback: 32 Channel (bandwidth: 64 Mbps)
- Video Direct Storage (Auto Register)
- Incoming: 320 Channel (bandwidth: 800 Mbps), Recording: 320 Channel (bandwidth: 800 Mbps), Outgoing: 320 Channel (bandwidth: 800 Mbps), Playback: 32 Channel (bandwidth: 64 Mbps)
- Backup Mode
- HDD, Peripheral USB storage device
- Controller
- Single controller
- Cache
- 8 GB by default (extendable to 64 GB)
- Thermal
- Works with camera for fire alarm, Temperature alarm, Temperature difference alarm, Hot spot, Cold spot, Smoking and calling
- Fan
- Intelligent speed regulation fan
- PTZ Smart Track
- Works with camera for manual tracking, Auto tracking, Click positioning and select positioning
- Interface Ports
- 1 eSATA Port, 1 RS-232 port, for debug or COM data transmission, 4 ports. 2 USB2.0 ports at the front panel and 2 USB3.0 ports at the rear panel , 1 HDMI Port, only for debug
- Ethernet
- 4 RJ-45 10/100/1000 Mbps self-adaptive Ethernet ports. (gigabit electrical port) 1 RJ-45 10/100 Mbps self-adaptive Ethernet ports. (100 Mbps electrical port)
- Protocols
- HTTP, HTTPS, TCP/IP, IPv4, RTSP, UDP, SMTP, NTP, DHCP, DNS, DDNS, InstaOn, iSCSI, FTP, SMB, NFS, ONVIF (Profile S, T and G), CGI, SDK
- Network Port Extension
- 4 × 1-GbE LAN ports (optional), 2 × 10-GbE optical fiber ports (optional)
- Storage Method
- Internal HDD and network disk
- Power Redundancy
- 1+1 redundant power
- Operating Temperature
- 0 °C to 45 °C (+32 °F to +113 °F)
- Operating Humidity
- 10%–80% (RH), non-condensing
- Power Supply
- 100-240 VAC 50-60 Hz
- Power Consumption
- <100 W (without HDD, idling) <500 W (all HDDs connected)
- Dimension
- Chassis: 446 mm × 261.4 mm × 736.5 mm Max. size: 482.6 mm (with hanger) × 264.1 mm × 736.5 mm
- Weight
- 35200 g
