Max 512 IP Camera Inputs
48 HDDs, SAS/SATA, Hot-Swap
Max 1024 Mbps incoming/recording/forwarding bandwidth
Single controller
64-bit High-performance multi-core processor
Supports RAID 0/1/5/6/10/50/60, JBOD, Hot spare
Supports video stream/ Picture direct storage mode and IPSAN storage mode
1 plus 1 redundant 80PLUS platinum power supply
Modular and drawer-like design
Supports N M cluster
- Processor
- 64-bit multi-core processor
- Operating System
- Embedded LINUX
- IP Camera Input
- 512 Channel
- User Interface
- Web
- Fan
- Dual ball-bearing fans
- IPSAN Function
- Dynamic online extension of logic volumes
- Video Direct Storage (Private Protocol)
- Up to 512-channel (1024 Mbps) access, storage, and forwarding; 32-channel (64 Mbps) online playback
- Video Direct Storage (Auto Register)
- Up to 512-channel (1024 Mbps) access, storage, and forwarding; 32-channel (64 Mbps) online playback
- IPSAN Mode
- Supported
- Video Storage
- Direct storage
- RAM
- 8 GB by default (extendable to 64 GB)
- Disk Bay
- 48
- Network Bandwidth
- 1×1GbE management port; 4×1GbE LAN ports
- Protocols
- RTP; RTCP; RTSP; UDP; HTTP; NTP; SNMP; iSCSI; FTP; SMB; NFS
- N+M Cluster
- Supported
- Hard Disk
- 1TB
- 2TB
- 3TB
- 4TB
- 5TB
- 6TB
- 8TB
- 10TB
- 12TB
- 14TB
- 16TB
- 2.5-inch and 3.5-inch HDD Support simultaneously connecting to SATA/SAS
- Disk Processing
- Dad Sector mapping
- RAID Instant Use
- Supported
- RAID-write Synchronization
- Supported
- Video Codec
- Access by cameras with encoding formats of MPEG4, MJPEG, H.264, H.265, and SVAC Access by multi-sensor cameras, thermal cameras, and panoramic cameras
- Playback
- Web playback, concentrated playback, slice playback, synchronous playback Search video by second Adjustable playback speed
- Backup Mode
- Back up video through USB, network, and eSATA
- Interface Ports
- 1×DB9 ; 1×HDMI
- Ethernet
- 1×1GbE management port; 4×1GbE LAN ports; 4×1-GbE LAN ports; 2×10-GbE optical fiber ports
- Controller
- Single Controller
- Hot Swapping
- Supported
- PCI-E
- 1×PCI-E X8; 1×PCI-E X
- Smart Phone
- iPhone, iPad, Android
- DISK
- 1×2.5 inch SATA
- Power Supply
- 100–127V/200–240 VAC, 50/60 Hz, 8A/4A
- Power Consumption
- <800W (include disks)
- Operating Temperature
- 0°C to 45°C (32°F to 113°F
- Operating Humidity
- 10%–80% (RH) (non-condensation)
- Storage Temperature
- -20°C to +70°C (–4°F to 158°F)
- Storage Humidity
- 5%–90% (RH) (non-condensation)
- Operating Altitude
- ≤5000 m
- Dimensions
- With hanger: 482.6 mm × 261.4 mm × 736.5 mm (19
- Weight
- 36 Kg
