- High-Quality Imaging
- 4MP resolution ensures superior image quality
- Efficient Compression
- Efficient H.265 compression technology saves bandwidth and storage
- Advanced DNR Technology
- 3D DNR technology delivers clean and sharp images
- Superior Imaging in Backlight
- Clear imaging against strong back light due to 120 dB true WDR technology
- Motorized Focus Lens
- Simplifies both installation and monitoring
- Easy Installation
- Features PoE technology for easy installation
- Durable Design
- Water and dust resistant (IP67) and vandal-resistant (IK10) for robust protection
- Lens
- 2.7 to 13.5 mm, horizontal FOV 96.7° to 29.7°, vertical FOV 51.7° to 16.7°, diagonal FOV 114.3° to 34.0° Wide: 1 m to ∞ Tele: 4.1 m to ∞
- DORI
- Wide: D: 64 m, O: 25.4 m, R: 12.8 m, I: 6.4 m Tele: D: 198 m, O: 78.6 m, R: 39.6 m, I: 19.8 m
- Video
- 50 Hz: 20 fps (2560 × 1440)
- 25 fps (1920 × 1080, 1280 × 720) 60 Hz: 20 fps (2560 × 1440)
- 30 fps (1920 × 1080, 1280 × 720) 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360) 60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360) 50 Hz: 1 fps (640 × 360) 60 Hz: 1 fps (640 × 360) Video Compression Main stream: H.265/H.264, Sub-stream: H.265/H.264/MJPEG Third stream: H.265/H.264
- Audio
- 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC)
- Network
- Security Up to 32 users 3 user levels: administrator, operator, and user Plug-in required live view: IE 10, IE 11, Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+
- Image
- Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance, adjustable by client software or web browser
- Interface
- Built-in memory card slot, support micro SD/micro SDHC/micro SDXC card, up to 512 GB Audio Built-in Microphone 1 input (line in), two-core terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium, 1 output (line out), two-core terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium
- Event
- Motion detection (support alarm triggering by specified target types (human and vehicle)), video tampering alarm, exception
- General
- Power 12 VDC ± 25%, 0.8 A, max. 9.6 W, Ø5.5 mm coaxial power plug, reverse polarity protection, PoE: IEEE 802.3af, Class 3, max. 12 W Startup and Operating Conditions Heartbeat, mirror, password reset via email, pixel counter, password protection, anti-banding
