Supports up to 64-channel IP camera inputs
Up to 2-ch@32 MP + 2-ch@8 MP/10-ch@8 MP/20-ch@4 MP/40-ch@1080p decoding capacity
Up to 400 Mbps incoming & Outgoing bandwidth
Efficient H.265 compression method for high-quality video and reduces storage space
Uses stream-over-TLS encryption technology to ensure safe and encrypted video transmission
Dual-stream recording optimizes bandwidth consumption
Equipped with two HDMI and two VGA ports, each supporting independent Output sources, and capable of delivering either 8K resolution or two simultaneous 4K video outputs
Enterprise-Grade Performance Support specialized cameras such as people counting, ANPR, and fisheye Robust streaming technology ensures seamless live viewing even under unstable network conditions RAID configurations (RAID 0, 1, 5, 6, 10) and N+M hot spare provide resilient data storage and mitigate data loss risks Equipped with redundant power supply for uninterrupted operation
Support specialized cameras such as people counting, ANPR, and fisheye
Robust streaming technology ensures seamless live viewing even under unstable network conditions
RAID configurations (RAID 0, 1, 5, 6, 10) and N+M hot spare provide resilient data storage and mitigate data loss risks
Equipped with redundant power supply for uninterrupted operation
Enhanced Intelligence & POS Integration Supports a wide range of intelligent video analytics (VCA) events Smart functions, such as VCA detection (motion, line crossing, intrusion, etc.), heat map, ANPR, and people counting can be configured POS data overlay available during live monitoring and playback, with recording and alerts triggered by POS activity
Supports a wide range of intelligent video analytics (VCA) events
Smart functions, such as VCA detection (motion, line crossing, intrusion, etc.), heat map, ANPR, and people counting can be configured
POS data overlay available during live monitoring and playback, with recording and alerts triggered by POS activity
User-friendly mobile app for seamless network and Ethernet access
Advanced technology ensures seamless and uninterrupted video streaming
Enables direct web access without requiring additional plug-ins or installations
Features 8 SATA interfaces & 1 eSATA interfaces for HDD connections
Supports 16-channel synchronous playback
Playback and download access protected by dual verification
- IP Camera Inputs
- Supports up to 64-channel IP camera inputs
- Decoding Capacity
- Up to 2-ch@32 MP + 2-ch@8 MP/10-ch@8 MP/20-ch@4 MP/40-ch@1080p decoding capacity
- High Bandwidth Capacity
- Up to 400 Mbps incoming & Outgoing bandwidth
- Enhanced Compression
- Efficient H.265 compression method for high-quality video and reduces storage space Uses stream-over-TLS encryption technology to ensure safe and encrypted video transmission Dual-stream recording optimizes bandwidth consumption
- High-Definition Video Output
- Equipped with two HDMI and two VGA ports, each supporting independent Output sources, and capable of delivering either 8K resolution or two simultaneous 4K video outputs
- Network Management
- Self-adaptive Ethernet interfaces: 2 RJ-45 10/100/1000 Mbps. User-friendly mobile app for seamless network and Ethernet access Advanced technology ensures seamless and uninterrupted video streaming Enables direct web access without requiring additional plug-ins or installations
- Self-adaptive Ethernet interfaces
- 2 RJ-45 10/100/1000 Mbps.
- Storage Capacity and Playback Options
- Features 8 SATA interfaces & 1 eSATA interfaces for HDD connections Supports 16-channel synchronous playback Playback and download access protected by dual verification
- Video and Audio
- *: When HDMI 1 output resolution is 8K, the maximum HDMI 2 output resolution is 1080p.
